Truck PTH403

Same ACM400 and Mercedes 4x4 as PTH402, However this one comes with a rated lifting arm and winch. Capable of hoisting 250KG loads into place, removing the requirement for additional machines onsite. Another very capable machine that is in very high demand.

Fleet Unit

PTH403

Working Height

40m

Maximum Radius

22m

Platform Weight Capacity

250kg / 400kg / 500kg

Model ACM400
Working Radius at Max Height 6m
Outrigger Spread 6.5m x 6.5m
Platform Size (LxWxH) (Expandable) 2.2-3.2m x .79m x 1.15m
Platform Rotation 180 degrees
Turntable Rotation 360 degrees
Truck Type Mercedes Atego 1629
Drive Type 4x4
Travelling Height 4.10m
Overall Length 10M
Overall Width 2.4 m
Weight 16 tonne
Country of Origin Australia
